|A) Seat tube length||400.0 mm||440.0 mm||480.0 mm||500.0 mm|
|B) Top tube length||581.1 mm||613.8 mm||645.1 mm||676.4 mm|
|C) Head tube length||115.0 mm||125.0 mm||130.0 mm||135.0 mm|
|D) Head tube angle||68.0 degrees||68.0 degrees||68.0 degrees||68.0 degrees|
|E) Seat tube angle||74.0 degrees||74.0 degrees||74.0 degrees||74.0 degrees|
|F) Chain stay length||440.0 mm||440.0 mm||440.0 mm||440.0 mm|
|G) Wheelbase||1122.8 mm||1156.5 mm||1188.4 mm||1220.3 mm|
|H) Stack||631.6 mm||640.9 mm||645.5 mm||650.1 mm|
|I) Reach||400 mm||430.0 mm||460.0 mm||490.0 mm|
|J) Bottom bracket drop||48.0 mm||48.0 mm||48.0 mm||48.0 mm|
|K) Fork length||Geometry designed with a 120 mm travel and 46 mm offset fork|
|Recommended rider height||155-170 cm||165-180 cm||175-190 cm||188-195 cm|
|Sizes||S1, S2, S3, S4|
|Material||Grade 9 titanium alloy|
|Color||Hand brushed titanium.|
|Front suspension||Rigid or 120 mm.|
|Rear suspension||How much do you squat?|
|Water bottle mounts||2 mounts.|
|Headset||44 mm ZS top | 56 mm ZS bottom. Headset not included with the frame.|
|Bottom bracket||73 mm BSA threaded.|
|Rear brake mount||160 mm Post Mount. Max rotor size 203 mm.|
|Rear axle||Aluminum through axle included with the frame. 12 mm x 148 mm Boost spacing. 180 mm total length with M12 x 1.5 mm thread.|
|Seat post diameter||31.6 mm|
|Seat clamp||34.9 mm titanium clamp included.|
|Max seat post insertion||S1 300 mm | S2 340 mm | S3 380 mm | S4 400 mm|
|Cable routing||External for the rear brake and rear derailleur. Internal for the dropper post.|
|Max tire size||29 x 2.6" or 27.5 x 2.8|
|Max chain ring size||34T single ring|
|Frame weight||2.1 kg for size S3|
Ships from Finland the next day if in stock.
Otherwise the estimated shipping time is mentioned in the product information.
We are here to help you out. For the thrill of that first-ride grin and beyond.
Don't take our word for it
Reached out to Pässilä to ask a load questions about their Rämäkkä frame, their response was quick, full of knowledge and friendly. My dream frame. Perfect balance between compliance and stiffness. Beautifully welded.
Super smooth! Like buying from a friend! Don't know if it's the titanium or the geo, but you guys got it just right!
I had lots of questions about geometry and specs, and all of them were answered. I finally have a Titanium frame!!!
She gets lots of attention everywhere. I built her up to my specs. I love this bike!!!
As an old fart been biking for a long long time but didn´t even have a clue how fun biking is before I bought Rämäkkä :)
Quality stuff and service. Geometry is awesome and modern for the rides I do and can do more. Quality of the frame is flawless. Very much allrounder bike.
I highly appreciated personal contacts via email during frame and component configuration. Also notifications on order status were punctual. Only hated the long waiting time.
Great quality frame, amazing service. It's a bit pricey but it's worth it.
Personal and good service with ability to solve my concerns regarding sizes etc. The product was
just what I expected it to be. Custom specs available which was very nice.
Purchasing process was kind and easy. Great manufacturing quality, perfect geometry for my needs, I like the colour a lot!
